Vibration transducers

The SOLID transducers are piezo-electric accelerometers of compression type; each individually tuned, with built-in pre­amplifier, designed for vibration monitoring of industrial machinery. The electrical signal is isolated from the transducer housing. Enhanced electronics and improved ambient characteristics deliver excellent performance in a very large area of applications.

The SOLID transducers and transmitters are designed to withstand the rigors of industrial environments. Stainless, acid-proof steel housings, case isolation, and hermetic sealing make them very robust.

Need an Ex version?

Transducers and connectors approved under the ATEX directive, for use in potentially explosive atmosphere.

Want to know more about our vibration transducers?

By clicking “Submit”, you agree that your message and personal details will be sent by email to relevant recipient(s) at SPM Instrument. You hereby also agree that SPM Instrument and its subsidiaries will have access to the information you have provided and that these data will be stored on our email server. The data will not be saved in any other way. We will not use this information to contact you about matters other than those specified in your request. We will not share your information with third parties.

Technical overview

Our vibration transducers come in a variety of sizes, configurations and specifications to perfectly suit your needs. All SOLID transducers are internally isolated. The frequency range is specified for the transducer when permanently installed. The measuring results will be affected at higher frequencies when using a magnetic foot.

Connection alternatives:


B = 2 pin connector MIL-C-5015
C = Integral cable*
CP = Integral cable*, adapter for protection tube

Vibration transducers with top entry/cable





Art. no.
Ex
Thread (t)
Connection
Frequency range
Sensitivity
SLD 121 - M6, M8, M10, UNF B, C, CP 2-1000 Hz 1.2 mV/m/s2
SLD 122 - M6, M8, M10, UNF B, C, CP 2-5000 Hz 4 mV/m/s2
SLD 144 - M6, M8, M10, UNF B, C, CP 2-10 000 Hz 10 mV/m/s2
SLD 243 Ex M6, M8, M10, UNF B, C, CP 2-10 000 Hz 5 mV/m/s2
SLD 244 Ex M6, M8, M10, UNF B, C, CP 2-10 000 Hz 10 mV/m/s2



Vibration transducers with side entry/cable





Art. no.
Ex
Thread (t)
Connection
Frequency range
Sensitivity
SLD 144S - M6, M8, UNF B, C, CP 2-10 000 Hz 10 mV/m/s2
SLD 244S Ex M6, M8, UNF B, C, CP 2-10 000 Hz 10 mV/m/s2



Vibration transducers MEMS with top entry





Art. no.
Ex
Thread (t)
Connection
Frequency range
Sensitivity
SLD 322B-M8 - M8 2-pin MIL 1-2000 Hz 4 mV/m/s2
SLD 322B-UNF - UNF 1/4" 2-pin MIL 1-2000 Hz 4 mV/m/s2
SLD 334B-M8 - M8 2-pin MIL 1-2000 Hz 10 mV/m/s2
SLD 334B-UNF Ex UNF 1/4 " 2-pin MIL 1-2000 Hz 10 mV/m/s2



Vibration transducers MEMS with side entry





Art. no.
Ex
Thread (t)
Connection
Frequency range
Sensitivity
SLD 334S-G - M3/Glue 2-pin MIL 1-2000 Hz 10 mV/m/s2



* Standard cable length is 3 meters, but optional lengths may be ordered (ex. SLDXXXC-M8-L where L = cable length in meters, max. 30 m).

Installation materials

Connectors, cables, and service box

We offer a wide range of connectors in composite or stainless-steel material. Composite material provides benefits such as vibration dampening and weight reduction, while stainless steel can withstand mechanical forces and works both in high and low temperatures, etc.

For our connectors, there are different types of cables, and to further secure the installation, we supply uncovered, acid-proof stainless steel conduits. These are protective covers slipped onto the cable and fixed to the transducer at the connector. Stainless steel cable clips are available for holding the conduit. For the protection of cable joints from moisture and water, a stainless, acid-proof steel service box is available.

Contact your SPM representative to learn more and discuss your needs.
